Summary
I wanted to create some custom cases/sleeves for my JUUL and needed an accurate model in order to get the proper tolerances for slip-fits and things alike. This model, by itself, will not print well at all. This model is best used as a skeleton to build your own creative ideas on. Model was drawn in SolidWorks2017.
Tag: Sleeve
-
JUUL Outer Sleeve 3D Print Model
-
Citroen, Peugeot rear cable sleeve clip 3D Print Model
Summary
This is a replacement clip for my Citroen C4 (2007) Coupe cable sleeve at the boot.
Since there was a problem with the cables (they would brake every now and then and cause shortcuts) removing the cable sometimes results in braking this little piece that is essential to hold the cable sleeve (FYI: my mechanic broke it and had it super glued, so after a while the whole sleeve would come off!).
It’s a replacement part that you cannot find anywhere (or no one would sell it to me!), so I had to print one.
The Citroen order code for this is : 96308075.80.
You will need to print 2 of those since one locks to each other (the locking is not great but a little bit of super glue to each other gets the job done).
Enjoy! 🙂
Print Settings
Printer:
Anet A8
Rafts:
No
Supports:
Yes
Resolution:
0.1
Infill:
100%
Notes:
It’s best to print it in nylon, ABS or PETG. PLA will be too fragile (brakes when sliding in the opening) and since in warm climates the temperature of the roof/ trunk can reach high temperatures I would recommend a much stronger/temperature proof filament.
Use supports if you want it printed as it is (on the side) I have noticed that printing it like this would result in being stronger when bending the flaps. However, if you rotate it you can print it without supports. -
Nintendo SNES Cartridge Dust Cover / Storage Sleeve 3D Print Model
Summary
This thing is a storage solution for SNES (Super Nintendo) cartridges. Normally, SNES cartridges don’t stand on their side. This cover fixes this problem so you can store your SNES carts vertically on a shelf conserving space and allowing you to see all your cartridges. This cover is modeled after the classic NES dust cover.
The walls are sized to print 2 shells thick on a Replicator 2. At 0.2mm layer height this takes ~1 hours 30 minutes to print.
NOTE: If you have trouble with your replicator creating a weak seam at the “zipper” try setting your “retractDistance” to “1.1” or “1.2”.
Print Settings
Printer Brand:
MakerBot Printer:
MakerBot Replicator 2 Rafts:
No Supports:
No Resolution:
0.2 mm Infill:
Doesn’t Matter Notes:
The walls are sized to print 2 shells thick on a Replicator 2. At 0.2mm layer height this takes ~1 hours 30 minutes to print.
NOTE: If you have trouble with your replicator creating a weak seam at the “zipper” try setting your “retractDistance” to “1.1” or “1.2”. -
19mm Socket Sleeve 3D Print Model
Summary
This is a sleeve that is placed on a 19mm deep wall socket. Its purpose is to protect rims from getting scratched when you remove the lug nuts. This model is for a regular chrome socket with a diameter of 1.01″ X 3.04″L (25.66mm X 77.22mm). The socket I used was made by Husky.
The sleeve has an inside diameter of 1.035″ ID and wall thickness of 0.02″. It is 3.03″ tall.
Post-Printing
I just wiped it with acetone to give it a smoother finish, but you don’t have to. -
LITHOPHANE FRAME 3D Print Model
Simple lamp FRAME
I want to share with you a simple lamp design that is illuminated with a
Chinese lantern … in addition to a lid with a halftone of the monkey amedio !! -
Octopus 3D model 3D Model
octopus toon squid scuttle poulp max sleeve fish devilfish 3d model animal octopod funny cute tentacle game ready sea ocean life low poly
-
Builder Wearing Orange Long Sleeve Coveralls Rigged 3D Model
Builder Wearing Orange Long Sleeve Coveralls Rigged is a high quality, photo real model that will enhance detail and realism to any of your rendering projects. The model has a fully textured, detailed design that allows for close-up renders, and was originally modeled in 3ds Max 2012 and rendered with V-Ray. Fidelity is optimal up to a 2k render. Renders have no postprocessing.Hope you like it!Builder Wearing Orange Long Sleeve Coveralls fully rigged with bipped bones and skin system in 3D Studio Max. You can easily position it the way you need or animate it the way your project requires using helpers in 3D Studio Max. Facial expressions can be controlled. See the turntable to get an idea of how rigging works.*********************************Features:- High quality polygonal model, correctly scaled for an accurate representation of the original object.- Models resolutions are optimized for polygon efficiency. (In 3ds Max, the Meshsmooth function can be used to increase mesh resolution if necessary.)- All colors can be easily modified.- Model is fully textured with all materials applied.- All textures and materials are included and mapped in every format.- 3ds Max models are grouped for easy selection, and objects are logically named for ease of scene management.- No part-name confusion when importing several models into a scene.- No cleaning up necessaryjust drop your models into the scene and start rendering.- No special plugin needed to open scene.- Model does not include any backgrounds or scenes used in preview images.- Units: cm*********************************File Formats:- 3ds Max 2012 V-Ray and standard materials scenes*********************************Textures Formats:- (18 .png) 4096 x 4096- (1 .png) 512 x 512*********************************3d Molier International is a team of 3D artists with over a decade of experience in the field. The company participated in various projects allowing us to learn our clients needs. Every model we build goes through thorough Quality assessment both visual and technical to make sure the assets look realistic and the models are of the best quality, which you can tell by looking at the renders none of the has any postprocessing. On the top of that all the models come with complete UVs and optimized topology, which allows you in no time alter geo or the textures if needed.Also check out our other models, just click on our user name to see complete gallery. 3d_molier International 2017
