axial fan support for E3D hotend (40×40) 3D Print Model
Summary
axial fan support for E3D hotend 40×40 -
BLV E3D V6 Bowden Extruder Mount 3D Print Model
Summary
This is a remix of the Pruisa i3 MK3 bowden extruder mount for the BLV linear rail mod with the E3D V6 Extruder.
I wanted to have a minimal and stiff mount which suits a 40 mm fan and the common BL-Touch (Smart).
Print Settings
Rafts:
No
Supports:
Yes
Notes:
Resolution and Infill is up to you – I used fairly high infill percentage to make it reliable and stiffAssembly
Nozzle to probe offset is in the images.
Assembly and what I used:
11x M3 – nuts
2x M3x30 – putting the 2 parts (base and cover) together
2x M3x23 – mounting the 5050Fan
4x M3x18 – 40 mm Fan + Cover (use whatever you’d like to)
3x M3x10 – Nozzle-Fan and BL-Touch
4x M3 screws to mount the base to the linear carrier -> see BLV -
E3D V6 Mount without Sensor (Hypercube Evolution) 3D Print Model
Summary
I have remixed the Extruder Mount for the E3D V6.
Now with 2 bigger holes for the Endstops and without Sensor.
Have fun with it 🙂 -
e3d v6 30mm layer fan 3D Print Model
Summary
30mm layer cooling fan for the E3d v6 hotend.
Designed to fit the monoprice mini but could be used on any printer with the same style mount.
Print Settings
Printer:
m200
Rafts:
No
Supports:
Yes
Resolution:
0.175
Infill:
30+
Notes:
You will need a m3x35mm Alan key head bolt and nut.
only test fitted to this mount.https://www.thingiverse.com/thing:1621387 -
P905X E3D V6 Bowden 3D Print Model
Summary
Version pour E3D V6 Bowden.
A faire avec support sur le lit -
Filament Cooler Fan Shroud, Dual Side, E3D Chimera and Cyclops 3D Print Model
Summary
Dual side shroud designed for lightness, access, and easy installation on a E3D Chimera or Cyclops hotend.
Printed with PETG, standing on fan mount surface.
Print Settings
Printer:
Banana 3D 330 Rafts:
Yes Supports:
No Resolution:
<= 0.2 Infill:
70 to 100% Notes:
Instead of a raft, a brim may be used with good results.
Heater block “socks” provided by E3D with their chimera and cyclops extruders should be used to minimize heat loss from peripheral air flow. -
Rock-solid E3D V6 mount for CR-10 with 12mm ABL sensor support 3D Print Model
Summary
Since I would like to change my CR-10 hotend to a more reiable one in terms of clogging (my PTFE tube alway melts after printing ABS at 250 degree) I’ve decided to go for an original E3D V& hotend. OK, it’s not the cheapest solution but in terms of construction it really convinced me since the PTFE tube is to going straight down to the heated block but ends in the cold zone of the hotend.
So I waas looking for a mount that allows me to attach my new hotend to my CR-10 and lets me add an ABL sensor in addition. Unfortunately I could not find any that was working for me. Some were too bulky, some had some construction issues and some simply did not support ABL or the ABL holder was too weak.
Therefore I’ve started to build one from scratch which can be found attached. It fits very well to the CR-10 plate and is easy to print (just print the STL files as they are. The mount.STL migh need some supports to be printed well).
Also the construction is rock-solid – no shaky ABL sensor and no movement of the whole construction.
The ABL Sensor has been placed as close as possible to the nozzle so measurement discrepancies should be as low as possible if the bed is a little uneven. For ABL I’ve used the following capacitive sensor: Heschen LJC12 A3–5-Z/BX.
Print Settings
Printer:
Creality CR-10 Rafts:
No Supports:
Yes Resolution:
0.2 mm Infill:
30% Notes:
Use ABS because of hotend temperatures. Some supports might be needed for mount.stl.
How I Designed This
The mount had been designed in 123D Cad. Used the sensor and the E3DV6 hotend as reference and also did some trial and error when designing the whole mount.
The first design was paying attention to get the sensor as close to the hotend as possible and to have a minimalistic design – anyway, it failed because the sensor was not getting close enough to the bed.
The second approach was much better since the sensor height was perfect now and a cable clamp had been added. However, when trying to mount it to my CR-10 I’ve noticed that the roller screw was preventing the attachment of the mount.
1st attempt2nd attempt
-
Anet A8 Laser bracket / Mount (Fits to E3D bracket) IN PROGRESS 3D Print Model
Summary
Anet A8 Laser bracket / Mount (Fits to E3D bracket) IN PROGRESS
I bought an laser to mount on my Anet a8.
But than i would need to take of my hotend, and recalibrate it every time.
Therefor i designed this bracket which i can mount next to my E3D V6.
I made this one for my 2.5W laser. -
E3d 40mm Fan Mount 3D Print Model
Summary
First Fusion 360 model I feel comfortable sharing, not perfect, but works great for me. Time for me to start contributing.
Made to fit the real E3d V6 hotend found here:http://a.co/hnA3NVu
Highly suggest PETG or Nylon, I printed mine in PETG and it’s rock solid and has not loosened in over 20hrs of printing.
Material – PETG or Nylon
Support – No
Infill – 100%
You will need to flip it 180º on the build plate as it’s upside down and don’t know how to correct it after the model has been drawn. 🙂
Feel free to leave constructive feedback.
Print Settings
Printer:
Anet A8 Rafts:
No Supports:
No Resolution:
0.1 Infill:
100 -
Monoprice Select Mini E3D V6 heat sink adaptor 3D Print Model
Summary
This is a bracket for holding the Bowden stype E3D V6 heat sink/hot end on the Monoprice Select Mini. It is sized so that it will be at the same level as the original that came with it so no adjustment to the z axis limit switch is necessary.
I used 2.5mm melt in threaded inserts, available from McMaster Carr:https://www.mcmaster.com/#94180A321.
I used 3mm melt in inserts for the clamp that holds the heat sink in, again from McMaster Carr.
Installation tool is right next to it on order page. You can also use a nut with a through drilling if you like.. -
Prusa I3 Single/Dual E3D Mount 3D Print Model
Summary
This collection of things provide a single or dual mount for E3D nozzle assemblies for the Prusa I3 printer.
Full details are provided in the encvlosed PDF document.
Print Settings
Printer Brand:
FlashForge Printer:
Dreamer Rafts:
Doesn’t Matter Supports:
No Resolution:
0.2 Infill:
20% -
FT-5 E3D Mount + Sensor Mount 3D Print Model
Summary
This is an updated version of the FT-5 E3D Stock Bowden Mount V4. I’ve add a mount for an inductive senor.
Print Settings
Printer Brand:
SeeMeCNC Printer:
Rostock MAX v2 Rafts:
No Supports:
Yes Resolution:
.25 Infill:
40% Notes:
REMOVE the supports from all holes!!
Printed with PETG 245C 70C bed. -
Monoprice Select Mini E3D 30mm single fan hotend and nozzle cooling 3D Print Model
Summary
I wanted to upgrade my MP select mini (V1) with an e3d hot end, but couldn’t find a holder for it that didn’t require an additional new fan. The closest I could find was Toolboxx’s upgrade for a single fan, but that still assumed I would be switching out the fan for a 40mm fan. So I did a simple remix.
All the 3D printed parts you need are included. You will need 2 M3x15mm screws and M3 bolts. -
E3D V6 40mm Fan Mount 3D Print Model
Summary
My E3D clone fan was just to loud and I had the feeling that I got heat creep, so I wanted to get a bigger (40mm) and therefore quiter fan.
I liked the snapon design of this (https://www.thingiverse.com/thing:354723) and this (https://www.thingiverse.com/thing:2058949) but it was just to bulky and didn’t quite fit with the hotend and carriage.
I also liked this (https://www.thingiverse.com/thing:506958) design with the angled fan, but the snap on didn’t fit for me.
So I kind of took both ideas and combined them in one design.
WIP ideas:
The only issue I have is, that the air blows through the E3D just fine, but has no propper path to escape, so it might flow down to the printing area. If anybody has suggestions, put it in the comments and I might try it. -
CTC Prusa i3 Pro B (E3D V6 Mount w/ Radial Fan mount) 3D Print Model
Summary
Created using TinkerCAD.
This mount was created to allow a 40mm radial fan to be attached to the front of the mount. The mount connects to the original carriage. It allows for a zip tie to be placed in order to hold all wiring.
Print Settings
Printer:
CTC Prusa I3 Rafts:
No Supports:
Yes Resolution:
.3mm Infill:
60% Notes:
Rotate top 180 degrees for the print. -
Raiscube R2 E3D Clone Mount, Clamp, and Parts Cooler 3D Print Model
Summary
Parts to upgrade Raiscube R2 to an E3D clone. -
FolgerTech FT-5 + E3D Part Cooling Fan 3D Print Model
Summary
Wanted to design a simple to print part cooling fan for the FolgerTech FT5 with a E3D V6 hotend.
No extra parts required, just some glue.
Dry fit both parts, once happy use some super glue to secure the shroud.
The mount was fitted for a 40mm x 40mm fan.
Print Settings
Printer Brand:
Printrbot Printer:
Printrbot Simple Metal Rafts:
No Supports:
Doesn’t Matter Resolution:
.2 Infill:
20 Notes:
May or may not need supports.
How I Designed This
Designed with TinkerCad -
Fixed Direct Drive Anet A6 E3D Hotend_for_S3D 3D Print Model
Summary
Ich habe dieses Objekt für einen Freund Repariert.
Auf dem Foto könnt ihr die Fehler sehen, die S3D gemacht hat / gefunden hat.
Cura sliced die Original Datei ohne Probleme.
I have repaired this object for a friend.
In the photo you can see the mistakes that S3D has made / found.
Cura sliced the original file without any problems
(Translated by Google) -
Ferarri California T 2015 3D model 3D Model
This highly detailed and ready to render at 3dsmax 3D Car Ferrari California T 2015 with high detailed interior. The 3d model was created on real car base. Model is created accurately, qualitatively and maximally close to the original.The model is completely ready for rendering, visualization and animation. It can be used as a production model without any requirement of additional modeling and texturing.Model formats: – .max(3d max 2014) – .c4d (Cinema 4D) – .obj (Multi Format), – .fbx (Multi Format) – .3ds (Multi Format)- The model is provided combined, all main parts are presented as separate parts therefore materials of objects are easy to be modified or removed and standard parts are easy to be replaced.- Renders are made in 3ds Max 2014 using vray 3.0. If you need any other formats im are more than happy to make them for you.- Vray materials, scanline materials and textures are also includedIf you have any questions or you need help with something, feel free to ask in comments or over my profile message. Please dont forget to rate if you like it! 🙂
-
Graphite Bushing E3D Titan Carriage for HyperCube
Summary
I would like to use Graphite Bushing on my newly built HyperCube, so I make one.
This mounts the E3D Titan with a Stepper Motor. You will also need an end stop, 2x 81130 graphite bushing, some M3x15 screws and M3 nuts, and super-glue or something that can stick everything together. Since I make it in separated part to print them more easily.
This is still a WIP
Print Settings
Printer:
MakerOne Rafts:
No Supports:
No Resolution:
0.2mm Infill:
25%
How I Designed This
Using SketchUp
