Summary
Using the source files from the Prusa Lack enclosure, I resized the magnet inserts for 20mm x 5mm x 2mm magnets, which were easier to find on eBay.
Print Settings
Printer Brand:
Prusa
Printer:
i3 MK3
Rafts:
No
Supports:
Doesn’t Matter
Resolution:
0.15 mm
Infill:
20%
Tag: 5mm
-
Prusa Lack Enclosure Door Handles for 20mm x 5mm x 2mm Magnets 3D Print Model
-
15mm x 5mm magnet holder 3D Print Model
Summary
15mm x 5mm magnet holder.
The hole for the magnet is a little undersized so the printed part can be heated a little (eg hot water if using PLA) and press fit. Or use some glue or if your magnet has a hole in center – a screw. I went with heating and press fit and its been solid.
i didn’t use any support when printing, the inside roof of the hole where the magnet goes is a fair span (15mm of unsupported distance) and so that particular surface wasn’t perfect but it worked fine and its behind the magnet anyway – doing this saves breaking out support material.
Print Settings
Printer:
aldi cocoon
Rafts:
No
Supports:
No
Resolution:
0.2mm
Infill:
no -
Yoda Extruder Spinner for MonoPrice Mini V2 5mm hole 3D Print Model
Summary
This is a remix of Force Yoda https://www.thingiverse.com/thing:2781362 reduced in size with a 5mm hole stand so it can be put on your Monoprice Select Mini v2 Extruder Rod.
Used:
PLA
220c on Extruder
50c on Bed
Supports: on all
Quality is up to you but in the Cura screenshot, you can see my inputs.
I used Speed 40
20% fill -
Flexible Shaft Coupler 5mm to 8mm 3D Print Model
Summary
Flexible Shaft Coupler – for 5mm Shaft with flat to 8mm Shaft. Print the coupler end pieces from PLA or ABS, the flexible insert with NinjaFlex/TPU, etc. Designed for 4mm screws and nuts to clamp to the shafts.
Print Settings
Rafts:
Doesn’t Matter Supports:
No Resolution:
0.2mm Infill:
40-80% for shaft clamps, 35% for flexible insert -
HS1177 or Micro FPV Cam Mount – 30.5 mm spacing 5mm standoff 3D Print Model
Summary
This mount will work for either an hs1177 or a micro fpv cam -
Grinder Holder Ø 41,5mm 3D Print Model
Summary
Just a simple holder for a Grinder with a size of Ø 41,5mm.
